Turning Insert: RCMT10T3M0-RS AH8005, Solid Carbide TiAlN Finish, Neutral, 0.1970″ Corner Radius, 0.0 ° N/A Round, Series RCMT
Item #: 20875605
Brand: Tungaloy
Model #: 6747782
Product Specifications
| Insert Style | RCMT |
| Insert Size Code | 10T3 |
| Insert Shape | Round |
| Insert Material | Solid Carbide |
| Manufacturer Grade | AH8005 |
| Hole Diameter (Decimal Inch) | 0.1730 |
| Maximum Depth of Cut (Decimal Inch) | 0.0787 |
| Inscribed Circle (Decimal Inch) | 0.3940 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.1560 |
| Corner Radius (Decimal Inch) | 0.1970 |
| Included Angle | 0.0 |
| Relief Angle | 7 |
| Series | RCMT |
| Coating Process | PVD |
| Rake | Positive |
| Wiper Edge | No |
| Number Of Cutting Edges | 4 |
| Primary Workpiece Material | Hard Material; Super-alloys & Titanium |
| Primary Workpiece Material Code | S; H |
| Ansi Code | RCMT10T3M0RSAH8005 |
| Iso Code | RCMT10T3M0-RS AH8005 |
| Chip Breaker | RS |
| Coating/Finish | TiAlN |
