Turning Insert: SCMT21.51-24 T9225, Solid Carbide TiCN, Al2O3 & TiN Finish, Neutral, 1/4″ Inscribed Circle, 0.0160″ Corner Radius, 90.0 ° N/A Square, Series SCMT
Item #: 20857751
Brand: Tungaloy
Model #: 6781105
Product Specifications
| Insert Style | SCMT |
| Insert Size Code | 21.51 |
| Insert Shape | Square |
| Insert Material | Solid Carbide |
| Manufacturer Grade | T9225 |
| Hole Diameter (Decimal Inch) | 0.1340 |
| Maximum Depth of Cut (Decimal Inch) | 0.1181 |
| Inscribed Circle (Inch) | 1/4 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.0940 |
| Corner Radius (Decimal Inch) | 0.0160 |
| Included Angle | 90.0 |
| Relief Angle | 7 |
| Series | SCMT |
| Coating Process | CVD |
| Rake | Positive |
| Wiper Edge | No |
| Number Of Cutting Edges | 4 |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Ansi Code | SCMT21.5124T9225 |
| Iso Code | SCMT070204-24 T9225 |
| Chip Breaker | 24 |
| Coating/Finish | TiCN; TiN; Al2O3 |
