Hubbell Wiring Device-Kellems - Pin & Sleeve Plugs & Connectors Connector Type: Connector Pin Configuration: 4
Item #: 54033022
Brand: Hubbell Wiring Device-Kellems
Model #: HBL430C9W
Product Specifications
Pin & Sleeve Plugs & Connectors; Connector Type: Connector ; Pin Configuration: 4 ; Number of Poles: 3 ; Amperage: 30 ; Voltage: 250 VAC ; Maximum Cord Grip Diameter (mm): 31.80
| Connector Type | Connector |
| Pin Configuration | 4 |
| Number of Poles | 3 |
| Amperage | 30 |
| Voltage | 250 VAC |
| Maximum Cord Grip Diameter (mm) | 31.80 |
| Maximum Cord Grip Diameter (Decimal Inch) | 1-1/4 |
| Minimum Cord Grip Diameter (mm) | 9-1/2 |
| Minimum Cord Grip Diameter (Decimal Inch) | 3/8 |
| Connector Diameter (mm) | 108-1/2 |
| Connector Diameter (Decimal Inch) | 4.2700 |
| Resistance Features | Impact Resistant; Moisture Resistant; Watertight |
| Color | Blue |
| Overall Length (Inch) | 9.0500 |
| Overall Length (mm) | 229.90 |
| Overall Length (Decimal Inch) | 9.0500 |
| Number of Phases | 3 |
| Ingress Protection Rating | IP67 |
| Material | Nylon |
| Standards Met | CSA C22.2 No. 182.1; CSA Certified; CSA File LR280C; IEC 60309-1; RoHS Compliant; UL 1682; UL 1686C2; UL File E146033; UL Listed |
