Seco - TCGT1.81.50.5 AL Grade TS2050 Carbide Turning Insert
Item #: 96228762
Brand: Seco
Model #: 03280823
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TCGT |
| Insert Size | 1.81.50.5 |
| Material | Carbide |
| Length (Decimal Inch) | 0.3791 |
| Inscribed Circle (Decimal Inch) | 0.2190 |
| Thickness (Decimal Inch) | 0.0940 |
| Corner Radius (Decimal Inch) | 0.0079 |
| Manufacturer's Grade | TS2050 |
| Coating | TiAlN/TiSiN |
| Chip Breaker | AL |
| Hole Diameter (Decimal Inch) | 0.0990 |
| Lead Angle | 93.000 |
| Rake | Positive |
| Rake Angle | 21 |
| Coating Process | PVD |
| Manufacturers Catalog Number | TCGT1.81.50.5F-AL |
| Included Angle | 60 |
| Cutting Direction | Right Hand |
| Insert Hand | Neutral |
| Series | TCGT |
| Insert Holding Method | Screw |
| Cutting Edge Style | Honed |
| Shape | Triangle |
