Indexable Boring Bar: E16H-STUPR13-D180, 18.00 mm Min Bore, 16.00 mm Shank Dia, 93.00° N/A Solid Carbide 100.0000″ OAL, Screw,
Item #: 19829134
Brand: Tungaloy
Model #: 6856844
Product Specifications
| Minimum Bore Diameter (mm) | 18.00 |
| Maximum Bore Depth (mm) | 80.00 |
| Toolholder Style | STUP |
| Tool Material | Solid Carbide |
| Shank Diameter (Decimal Inch) | 16.0000 |
| Shank Diameter (mm) | 16.00 |
| Shank Diameter (Inch) | 16 |
| Overall Length (Decimal Inch) | 100.0000 |
| Overall Length (mm) | 100.00 |
| Overall Length (Inch) | 100 |
| Compatible Insert Size Code | 2.52 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Triangle |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Rake Angle | -3.00 |
| Lead Angle | 93.00 |
| Series | STUP |
| Insert Inscribed Circle (Inch) | 5/16 |
| Insert Inscribed Circle (Decimal Inch) | 0.3130 |
| Compatible Insert Thickness (Decimal Inch) | 0.1250 |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (mm) | 9.00 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
