Indexable Grooving Toolholder: CGWSL2020-FLL5TP, Uses 5 Inserts, No
Item #: 19812718
Brand: Tungaloy
Model #: 6801764
Product Specifications
| Toolholder Type | Face Grooving |
| Insert Seat Size | 5 |
| Cutting Direction | Left Hand |
| Maximum Depth of Cut (mm) | 6.00 |
| Minimum Groove Width (mm) | 5.00 |
| Toolholder Style | CGWS |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | 5 |
| Shank Width/Diameter (mm) | 20.00 |
| Shank Height (mm) | 20.00 |
| Series | CGWS |
| Overall Length (mm) | 152.00 |
| Cutting Tool Application | Grooving; Facing |
| Back of Bar to Cutting Edge (mm) | 27.00 |
| Minimum Hole Diameter (mm) | 150.00 |
| Minimum Hole Diameter (Decimal Inch) | 150.0000 |
| Head Height (Decimal Inch) | 20.0000 |
| Head Height (Inch) | 20 |
| Head Height (mm) | 20.00 |
| Head Length (mm) | 48.50 |
| Primary Workpiece Material | Universal |
| Toolholder Material | Steel |
| Coolant Through | No |
