Combination Chamfer & Countersink Drills; Maximum Drill Diameter (Decimal Inch): 6.90 mm; Maximum Drill Diameter (mm): 6.90 mm; Minimum Drill Diameter (mm): 6.50 mm; Shank Type: Weldon Flat; Body Shank Diameter (mm): 12.00 mm; Chuck Shank Diameter (mm): 1
Item #: 19302900
Brand: Ingersoll Cutting Tools
Model #: 6135628
Product Specifications
| Maximum Drill Diameter (Decimal Inch) | 6.90 mm |
| Maximum Drill Diameter (mm) | 6.90 mm |
| Minimum Drill Diameter (mm) | 6.50 mm |
| Shank Type | Weldon Flat |
| Body Shank Diameter (mm) | 12.00 mm |
| Chuck Shank Diameter (mm) | 12.00 mm |
| Drill Shank Diameter (Decimal Inch) | 6.90 mm |
| Compatible Insert Style | KOMT; TMA; TKA |
| Number of Drill Inserts | 1 |
| Compatible Insert Size Code | 0501; 0650 |
| Chamfer Angle | 45.000 |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Body Diameter (mm) | 0.5320 |
| Overall Length (mm) | 95.25 |
| Overall Length (Decimal Inch) | 95.25 |
| Tool Material | Steel |
| Cutting Direction | Right Hand |
| Coated | Coated |
| Coating | (TiN) |
| Number Of Flutes | 2 |
| Tool Application | Chamfering; Solid Drilling |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Included Angle | 140.00 |
| Insert Holding Method | Screw |
| Shank Length (Decimal Inch) | 25.65 mm |
| Shank Length (mm) | 25.65 mm |
| Through Coolant | Normal Pressure |
| Series | TC |
