Laydown Threading Inserts; Insert Style: 11IR; Insert Size Code: 11; Insert Material: Solid Carbide; Manufacturer Grade: PR1535; Threads Per Inch: 14.00; Thread Type: Internal; Thread Standard: Tapered Pipe; Insert Hand: Right Hand; Thickness (Inch): 1/8;
Item #: 18302612
Brand: Kyocera
Model #: TLC19740
Product Specifications
| Insert Style | 11IR |
| Insert Size Code | 11 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | PR1535 |
| Thread Type | Internal |
| Thread Standard | Tapered Pipe |
| Insert Hand | Right Hand |
| Thickness (Inch) | 1/8 |
| Included Angle | 55 |
| Chipbreaker | TQ |
| Series | 11IR |
| Coating Process | PVD |
| Inscribed Circle (Inch) | 1/4 |
| Corner Radius (Decimal Inch) | 0.0087 |
| Hole Diameter (Mm) ( - 0 Decimals) | 3.00 |
| Number of Teeth Per Side | 3 |
| Cutting Direction | Right Hand |
| Manufacturers Catalog Number | 11IR14BSPTTQPR1535 |
| Relief Angle | 0 |
| Teeth Per Inch | 14.00 |
| Coating/Finish | TiAlN |
