Brand: Widia / Part #: 2545219
Item #: 33977729
Brand: Widia
Model #: 2545219
Product Specifications
| Mill Diameter (mm) | 12.00 |
| Length of Cut (mm) | 12.00 |
| End Mill Material | Solid Carbide |
| Coating/Finish | TiAlN |
| Chipbreaker | No |
| Number Of Flutes | 2 |
| End Type | Single |
| Extended Reach | Yes |
| Undercutting | No |
| Helix Style | Medium |
| Material Removal Type | Finishing |
| Shank Diameter (Decimal Inch) | 0.4724 |
| Neck Diameter (Decimal Inch) | 11.5000 |
| Nose Radius (Decimal Inch) | 6.0000 |
| Reach Length (mm) | 12.00 |
| Overall Length (mm) | 125.00 |
| Maximum Helix Angle | 30.00 |
| Minimum Helix Angle | 30.00 |
| Primary Workpiece Material | Hard Material |
| Primary Workpiece Material Code | H |
| Secondary Workpiece Material | Steel |
| Secondary Workpiece Material Code | P |
| Material Grade | WU10PE |
| Flute Direction | Right Hand |
| Cutting Direction | Right Hand |
| Series | 70N1 |
| Flute Type | Medium |
| Coolant Through | No |
