Gates - Belts Belt Style: Synchronous Belt Section: Round
Item #: 96339346
Brand: Gates
Model #: 90052195
Product Specifications
Belts; Belt Style: Synchronous ; Belt Section: Round ; Outside Length: 16.441 (Decimal Inch); Outside Length: 417.60 (mm); Belt Width: 0.354 (Decimal Inch); Belt Width: 9.00 (mm)
| Belt Style | Synchronous |
| Belt Section | Round |
| Outside Length (Decimal Inch) | 16.441 |
| Outside Length (mm) | 417.60 |
| Belt Width (Decimal Inch) | 0.354 |
| Belt Width (mm) | 9.00 |
| Belt Number | 420-3M-09 |
| Belt Internal Length (Decimal Inch) | 16.54 |
| Belt Internal Length (mm) | 420.00 |
| Number of Ribs | 0.000 |
| Number of Teeth | 140 |
| Belt Pitch | 3 mm |
| Material | Neoprene |
| Belt Height | 0.138 |
| Color | Black |
| Style | Synchronous |
| Maximum Temperature (F) | 180 |
