Square End Mill: 21/64'' Dia, 1/2'' LOC, 3/8'' Shank Dia, 2'' OAL, 2 Flutes, Solid Carbide Single End, AlTiN Finish, 30 ° Helix, Centercutting, RH Cut, RH Flute
Item #: 15267644
Brand: Micro 100
Model #: SEM-328-02X
Product Specifications
| Mill Diameter (Inch) | 21/64 |
| Mill Diameter (Decimal Inch) | 0.3281 |
| Number Of Flutes | 2 |
| Length of Cut (Inch) | 1/2 |
| End Mill Material | Solid Carbide |
| End Type | Single |
| Centercutting | Yes |
| Cutting Direction | Right Hand |
| Shank Diameter (Inch) | 3/8 |
| Finish/Coating | AlTiN |
| Overall Length (Inch) | 2 |
| Helix Angle | 30 |
| Variable Helix | No |
| Variable Index | No |
| Extended Reach | No |
| Length Of Cut Range (Decimal Inch) | 0.5000 - 0.6000 |
| Length of Cut (Decimal Inch) | 0.5000 |
| Shank Diameter (Decimal Inch) | 0.3750 |
| Overall Length (Decimal Inch) | 2.0000 |
| Flute Direction | Right Hand |
| Helix Style | Medium |
