SGS - Ball End Mills; Mill Diameter (Decimal Inch): 0.0560 ; Number of Flutes: 4 ; Length of Cut (Decimal Inch): 0.1680 ; Material: Solid Carbide ; Overall Length (Inch): 1-1/2 ; Shank Diameter (Inch): 1/8
Item #: 14651483
Brand: SGS
Model #: 00933
Product Specifications
Ball End Mills; Mill Diameter (Decimal Inch): 0.0560 ; Number of Flutes: 4 ; Length of Cut (Decimal Inch): 0.1680 ; Material: Solid Carbide ; Overall Length (Inch): 1-1/2 ; Shank Diameter (Inch): 1/8
| Mill Diameter (Decimal Inch) | 0.0560 |
| Number of Flutes | 4 |
| Length of Cut (Decimal Inch) | 0.1680 |
| Material | Solid Carbide |
| Overall Length (Inch) | 1-1/2 |
| Shank Diameter (Inch) | 1/8 |
| Finish/Coating | Uncoated |
| Single or Double End | Single |
| Helix Angle | 30 |
| Variable Index | No |
| Variable Helix | No |
| Extended Reach | No |
| Flute Type | Spiral |
| Shank Diameter Tolerance (Decimal Inch) | h6 |
| Length Type | Regular |
| Series/List | M4B |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| PSC Code | 3455 |
