SGS - Ball End Mills; Mill Diameter (mm): 2.60 ; Mill Diameter (Decimal Inch): 0.1024 ; Number of Flutes: 4 ; Length of Cut (mm): 7.8000 ; Length of Cut (Decimal Inch): 0.3000 ; Material: Solid Carbide
Item #: 14626774
Brand: SGS
Model #: 02975
Product Specifications
Ball End Mills; Mill Diameter (mm): 2.60 ; Mill Diameter (Decimal Inch): 0.1024 ; Number of Flutes: 4 ; Length of Cut (mm): 7.8000 ; Length of Cut (Decimal Inch): 0.3000 ; Material: Solid Carbide
| Mill Diameter (mm) | 2.60 |
| Mill Diameter (Decimal Inch) | 0.1024 |
| Number of Flutes | 4 |
| Length of Cut (mm) | 7.8000 |
| Length of Cut (Decimal Inch) | 0.3000 |
| Material | Solid Carbide |
| Overall Length (mm) | 38.0000 |
| Shank Diameter (mm) | 3.0000 |
| Finish/Coating | AlTiN |
| Single or Double End | Single |
| Helix Angle | 30 |
| Variable Index | No |
| Variable Helix | No |
| Extended Reach | No |
| Flute Type | Spiral |
| Shank Diameter Tolerance (Decimal Inch) | h6 |
| Length Type | Regular |
| Series/List | M4BM |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| PSC Code | 3455 |
