SNMG642-QM 4425 Carbide Turning Insert Al2O3/TiN/TiCN Finish, Neutral, 3/4″ Inscribed Circle, 0.0313″ Corner Radius, 1/4″ Thick, Trigon
Item #: 10208148
Brand: Sandvik Coromant
Model #: 7861092
Product Specifications
| Insert Style | SNMG |
| Insert Shape Code | S |
| Insert Size Code | 1906 |
| Insert Shape | Square |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Solid Carbide |
| Manufacturer Grade | 4425 |
| Hole Diameter (Mm) ( - 0 Decimals) | 7.93 |
| Hole Diameter (Decimal Inch) | 0.3120 |
| Inscribed Circle (Inch) | 3/4 |
| Inscribed Circle (Decimal Inch) | 0.7500 |
| Insert Holding Method | Screw; Clamp |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 1/4 |
| Insert Thickness (Decimal Inch) | 0.2500 |
| Corner Radius (Inch) | 1/32 |
| Corner Radius (mm) | 0.79 |
| Corner Radius (Decimal Inch) | 0.0313 |
| Relief Angle | 0 |
| Series | T-Max P |
| Coating Process | CVD |
| Wiper Edge | No |
| Number Of Cutting Edges | 8 |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material | Cast Iron |
| Secondary Workpiece Material Code | K |
| Ansi Code | SNMG642QM4425 |
| Iso Code | SNMG 19 06 08-QM 4425 |
| Manufacturers Catalog Number | SNMG 642-QM |
| Cutting Direction | Neutral |
| Chip Breaker | QM |
| Industry Standard Number | SNMG 19 06 08-QM 4425 |
| Coating/Finish | TiCN; TiN; Al2O3 |
 | |
| MSC Part # | 10208148 |
| Mfr Part # | 7861092 |
| Country of OriginCountry of Origin is subject to change | Sweden |
