Indexable Boring Bar: A50U DCLNL 16, 95.00° N/A Steel 13.7800″ OAL, Clamp,
Item #: 10030674
Brand: Ceratizit
Model #: 7055785000
Product Specifications
| Minimum Bore Diameter (Decimal Inch) | 2.4803 |
| Maximum Bore Depth (Decimal Inch) | 7.8740 |
| Toolholder Style | DCLNL |
| Tool Material | Steel |
| Shank Diameter (Decimal Inch) | 1.9685 |
| Overall Length (Decimal Inch) | 13.7800 |
| Overall Length (mm) | 13.78 |
| Compatible Insert Size Code | CN..54. |
| Insert Holding Method | Clamp |
| Compatible Insert Shape | Diamond |
| Insert Included | No |
| Rake | Negative |
| Cutting Direction | Left Hand |
| Rake Angle | 0.00 |
| Lead Angle | 95.00 |
| Series | MaxiLock-D |
| Insert Inscribed Circle (Inch) | 5/8 |
| Insert Inscribed Circle (Decimal Inch) | 0.6250 |
| Compatible Insert Thickness (Decimal Inch) | 0.2500 |
| Multi-use Tool | No |
| Cutting Tool Application | Boring |
| Back of Bar to Cutting Edge (Decimal Inch) | 2.3623 |
| Center to Cutting Edge (Decimal Inch) | 1.3780 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
