Brand: Widia / Part #: 2832689
Item #: 97595300
Brand: Widia
Model #: 2832689
Product Specifications
| Boring Bar Type | Micro Boring |
| Cutting Direction | Right Hand |
| Material | Solid Carbide |
| Material Grade | Submicron |
| Maximum Bore Depth (Decimal Inch) | 0.8250 |
| Shank Diameter (Decimal Inch) | 5/32 |
| Overall Length (Inch) | 1-7/8 |
| Finish Coating | Titanium Nitride |
| Manufacturer Grade | CG5 |
| Series | BP |
| Coating Process | CVD |
| Maximum Depth of Cut (mm) | 0.08 |
| Minimum Bore Diameter (Inch) | 1/4 |
| Primary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
| Relief Angle | -3.000 |
| Secondary Workpiece Material | Non-Ferrous Metal; Stainless Steel; Cast Iron; Steel |
