Indexable Boring Bar: A40T-PCLNR12-D500, 50.00 mm Min Bore, 40.00 mm Shank Dia, 95.00° N/A Steel 300.0000″ OAL, Lever,
Item #: 09993783
Brand: Tungaloy
Model #: 6855904
Product Specifications
| Minimum Bore Diameter (mm) | 50.00 |
| Maximum Bore Depth (mm) | 160.00 |
| Toolholder Style | PCLN |
| Tool Material | Steel |
| Shank Diameter (Decimal Inch) | 40.0000 |
| Shank Diameter (mm) | 40.00 |
| Shank Diameter (Inch) | 40 |
| Overall Length (Decimal Inch) | 300.0000 |
| Overall Length (mm) | 300.00 |
| Overall Length (Inch) | 300 |
| Compatible Insert Size Code | 43 |
| Insert Holding Method | Lever |
| Compatible Insert Shape | Diamond |
| Insert Included | No |
| Rake | Negative |
| Cutting Direction | Right Hand |
| Rake Angle | -10.00 |
| Lead Angle | 95.00 |
| Series | PCLN |
| Insert Inscribed Circle (Inch) | 1/2 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
| Compatible Insert Thickness (Decimal Inch) | 0.1870 |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (mm) | 27.00 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
