Indexable Boring Bar: T12M-SCLPL08, 16.00 mm Min Bore, 12.00 mm Shank Dia, 95.00° N/A Tsuppari (Shank) 150.0000″ OAL, Screw,
Item #: 09991084
Brand: Tungaloy
Model #: 6807445
Product Specifications
| Minimum Bore Diameter (mm) | 16.00 |
| Maximum Bore Depth (mm) | 60.00 |
| Toolholder Style | SCLP |
| Tool Material | Tsuppari (Shank) |
| Shank Diameter (Decimal Inch) | 12.0000 |
| Shank Diameter (mm) | 12.00 |
| Shank Diameter (Inch) | 12 |
| Overall Length (Decimal Inch) | 150.0000 |
| Overall Length (mm) | 150.00 |
| Overall Length (Inch) | 150 |
| Compatible Insert Size Code | 2.51.5 |
| Insert Holding Method | Screw |
| Compatible Insert Shape | Diamond |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Left Hand |
| Rake Angle | -3.00 |
| Lead Angle | 95.00 |
| Series | SCLP |
| Insert Inscribed Circle (Inch) | 5/16 |
| Insert Inscribed Circle (Decimal Inch) | 0.3130 |
| Compatible Insert Thickness (Decimal Inch) | 0.0940 |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (mm) | 9.00 |
| Primary Workpiece Material | Universal |
| Coolant Through | No |
