Indexable Boring Bar: A25R-PTFNL1104-D320, 32.00 mm Min Bore, 25.00 mm Shank Dia, 91.00° N/A Steel 200.0000″ OAL, Lever,
Item #: 09975053
Brand: Tungaloy
Model #: 6733322
Product Specifications
| Minimum Bore Diameter (mm) | 32.00 |
| Maximum Bore Depth (mm) | 100.00 |
| Toolholder Style | PTFN |
| Tool Material | Steel |
| Shank Diameter (Decimal Inch) | 25.0000 |
| Shank Diameter (mm) | 25.00 |
| Shank Diameter (Inch) | 25 |
| Overall Length (Decimal Inch) | 200.0000 |
| Overall Length (mm) | 200.00 |
| Overall Length (Inch) | 200 |
| Compatible Insert Size Code | 23 |
| Insert Holding Method | Lever |
| Compatible Insert Shape | Triangle |
| Insert Included | No |
| Rake | Negative |
| Cutting Direction | Left Hand |
| Rake Angle | -12.00 |
| Lead Angle | 91.00 |
| Series | PTFN |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Compatible Insert Thickness (Decimal Inch) | 0.1870 |
| Cutting Tool Application | Boring |
| Center to Cutting Edge (mm) | 17.00 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
