Indexable Boring Bar: A32S SSSCR 12, 40.00 mm Min Bore, 32.00 mm Shank Dia, 45.00° N/A Steel 258.3000″ OAL, Screw Clamping,
Item #: 09973173
Brand: Ceratizit
Model #: 70720232
Product Specifications
| Minimum Bore Diameter (mm) | 40.00 |
| Maximum Bore Depth (mm) | 128.00 |
| Toolholder Style | SSSCR |
| Tool Material | Steel |
| Shank Diameter (Decimal Inch) | 32.0000 |
| Shank Diameter (mm) | 32.00 |
| Shank Diameter (Inch) | 32 |
| Overall Length (Decimal Inch) | 258.3000 |
| Overall Length (mm) | 258.30 |
| Compatible Insert Size Code | SC..43. |
| Insert Holding Method | Screw Clamping |
| Compatible Insert Shape | Square |
| Insert Included | No |
| Rake | Positive |
| Cutting Direction | Right Hand |
| Rake Angle | 7.00 |
| Lead Angle | 45.00 |
| Series | MaxiLock-S |
| Insert Inscribed Circle (Inch) | 1/2 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
| Compatible Insert Thickness (Decimal Inch) | 0.1875 |
| Multi-use Tool | No |
| Cutting Tool Application | Boring |
| Back of Bar to Cutting Edge (mm) | 38.00 |
| Center to Cutting Edge (mm) | 22.00 |
| Primary Workpiece Material | Universal |
| Coolant Through | Yes |
