SGS - 5/8" Diam, 0.04" Radius, 1-1/4" Length of Cut, 4 Flute, Solid Carbide, Corner Radius End Mill - Ti-NAMITE-X Coated, Single End, 3-1/2" Overall Length, 5/8" Shank Diam, Spiral Flute, Variable° Helix, Centercutting, Regular Length
Item #: 08635021
Brand: SGS
Model #: 36807
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
"Ti-NAMITE-A is a multi-layed coating composed of aluminum titanium nitride (AlTiN) and cobalt. It is yed for high speed and dry cutting. It is commonly used on cast iron, hardened tool steels and heat resistant alloys. Ti-NAMITE-A is a proprietary coating exclusive to SGS Tool Company.
| Product Specifications | |
|---|---|
| Mill Diameter (Inch) | 5/8 |
| Mill Diameter (Decimal Inch) | 0.6250 |
| End Type | Corner Radius |
| Corner Radius (Decimal Inch) | 0.0400 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | Ti-NAMITE-X |
| Length of Cut (Inch) | 1-1/4 |
| Length of Cut (Decimal Inch) | 1.2500 |
| Shank Diameter (Inch) | 5/8 |
| Overall Length (Inch) | 3-1/2 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | Variable |
| Material Grade | Micrograin |
| Single or Double End | Single |
| Minimum Helix Angle | 35 |
| Maximum Helix Angle | 38 |
| Length Type | Regular |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Mill Diameter Tolerance (Decimal Inch) | +0.000/-0.002 |
| Corner Radius Tolerance (Decimal Inch) | +0.000/-0.002 |
| Shank Diameter Tolerance (Decimal Inch) | +0.00000/-0.00043 |
| Extended Reach | No |
