Lapeer - 50 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp - 1/8 NPTF Port, 95° Bar Opening, 1" Height Under Bar
Item #: 08106502
Brand: Lapeer
Model #: AO-50
Exact Tooling IR#: 04
Features and Benefits
Horizontal mounts indicate that the cylinder is mounted parallel to the clamping bar's closed position.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Horizontal |
| Holding Capacity - Inner (Lb.) | 50 |
| Holding Capacity - Inner (kg) | 23 |
| Height Under Bar (mm) | 25.40 |
| Height Under Bar (Inch) | 1 |
| Height Under Bar (Decimal Inch) | 1.0000 |
| Port Size | 1/8 NPTF |
| Bar Opening (Degrees) | 95.00 |
| Width Distance Between Mount Holes (mm) | 26.99 |
| Width Distance Between Mount Holes (Inch) | 1-1/16 |
| Bar Extension (Decimal Inch) | 2.0000 |
| Bar Extension (mm) | 50.80 |
| Overall Closed Length (mm) | 247.70 |
| Overall Closed Length (Inch) | 9-3/4 |
| Overall Open Height (Inch) | 2-11/64 |
| Air Requirement (psi) | 80 to 85 |
| Mounting Hole Size (mm) | 5.16 |
| Mounting Hole Size (Decimal Inch) | 0.2030 |
| Bar Style | U-Bar |
| Bar End Type | Open |
| Includes | Spindle Assembly |
