Profiling Insert: RCMK23 KCU10B, .358" Thick, 1/4" Inscribed Circle
Item #: 05074554
Brand: Kennametal
Model #: 7096366
Product Specifications
| Insert Style | RCMK |
| Insert Size Code | 23 |
| Insert Material | Carbide |
| Manufacturer Grade | KCU10B |
| Thickness (Inch) | .358 |
| Insert Height (Decimal Inch) | 0.3580 |
| Thickness (mm) | 9.0900 |
| Insert Height (mm) | 9.09 |
| Maximum Depth of Cut (Decimal Inch) | 0.0833 |
| Maximum Depth of Cut (mm) | 2.12 |
| Insert Holding Method | Pin |
| Insert Hand | Neutral |
| Corner Radius (Decimal Inch) | 0.1250 |
| Corner Radius (mm) | 3.18 |
| Included Angle | 0.00 |
| Relief Angle | 7.500 |
| Inscribed Circle (Inch) | 1/4 |
| Inscribed Circle (Decimal Inch) | 0.2500 |
| Inscribed Circle (mm) | 6.35 |
| Coating Process | PVD |
| Number Of Cutting Edges | 6 |
| Iso Code | RCMK060400 |
| Rake Angle | 7.500 |
| Coating/Finish | AlTiN |
| Thickness (Decimal Inch - 4 Decimals) | 0.3580 |
| Width (Decimal Inch - 4 Decimals) | 0.3580 |
| Width (mm - 2 Decimals) | 9.09 |
| UNSPSC Code | 23242105 |
