Iscar - 45° Lead Angle, 14.1mm Max Cut Diam, 6mm Min Cut Diam, 4mm Max Depth of Cut, Indexable Chamfer and Angle End Mill - 1 Insert, X/Q/SOMT-HQ Insert Style, 70mm Overall Length, Straight Shank
Item #: 07530512
Brand: Iscar
Model #: 3110608
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Minimum Cutting Diameter (Decimal Inch) | 0.2362 |
| Minimum Cutting Diameter (mm) | 6.00 |
| Maximum Cutting Diameter (mm) | 14.10 |
| Maximum Cutting Diameter (Decimal Inch) | 0.5551 |
| Shank Type | Weldon |
| Shank Diameter (mm) | 12.00 |
| Shank Diameter (Decimal Inch) | 0.4724 |
| Lead Angle | 45 |
| Overall Length (mm) | 70.00 |
| Overall Length (Decimal Inch) | 2.7559 |
| Insert Style | X/Q/SOMT-HQ |
| Series | Heliquad |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.1575 |
| Maximum Depth of Cut (mm) | 4.00 |
| Number of Cutter Inserts | 1 |
| Toolholder Style | E45X |
| Head Length (mm) | 19.00 |
| Head Length (Decimal Inch) | 0.7480 |
| Weldon Flat | Yes |
