GC/Waldom - 0.638 Inch Mount Hole, Pushbutton Switch Only - Square, Momentary (MO)
Item #: 07522055
Brand: GC/Waldom
Model #: 35-3412
Exact Tooling IR#: 04
Features and Benefits
Pushbutton switches are designed with the front side of the switch outfacing on the panel. Used in conjunction with a contact block, these switches are designed to activate machinery by button that is pressed and released. Applications include starting and stopping the machine.
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (Decimal Inch) | 0.6380 |
| Switch Type | Pushbutton Switches Only |
| Pushbutton Shape | Square |
| Operation Type | Momentary (MO) |
| Pushbutton Material | Plastic |
| Amperage | 0.20 @ 220 VDC; 4 @ 250 VAC |
| Voltage | 220 VDC; 250 VAC |
| Contact Configuration | NO/NC |
| Contact Form | SPDT |
| Terminal Type | Solder Eyelet |
| Bushing Length (Decimal Inch) | 0.2950 |
| Standards Met | CSA; UL Recognized |
