Associated Spring Raymond - 12.2mm OD, 0.97mm Wire, 1-1/4" Free Length, Compression Spring - 7.5 Lb Spring Rating, 26.69 N Max Work Load, Music Wire
Item #: 07490592
Brand: Associated Spring Raymond
Model #: C04800381250M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 12.19 |
Outside Diameter (Decimal Inch) | 0.4800 |
Free Length (mm) | 31-3/4 |
Free Length (Decimal Inch) | 1-1/4 |
Spring Rate Pounds per Inch (Pounds) | 7.5000 |
Maximum Work Load (N) | 26.69000053 |
Solid Height (mm) | 6.58 |
Solid Height (Decimal Inch) | 0.2590 |
Material | Music Wire |
Wire Size (mm) | 0.97 |
Wire Size (Decimal Inch) | 0.0380 |
