GC/Waldom - 0.315 Inch Mount Hole, Miniature Pushbutton Switch Only - Round, Black Pushbutton, Nonilluminated, Momentary (MO), Off-On
Item #: 06969554
Brand: GC/Waldom
Model #: 35-409
Exact Tooling IR#: 04
Features and Benefits
Miniature pushbutton switches are designed to activate machinery by button that is pressed and released. They are smaller in size and used where limited space is available. Applications include starting and stopping the machine or process
Nonilluminated pushbuttons do not feature a light within the button.They are commonly used in areas where added light is not needed.
| Product Specifications | |
|---|---|
| Mounting Hole Diameter (Decimal Inch) | 0.3150 |
| Switch Type | Miniature Pushbutton Switches Only |
| Pushbutton Shape | Round |
| Pushbutton Color | Black |
| Operator Illumination | NonIlluminated |
| Operation Type | Momentary (MO) |
| Switch Sequence | Off-On |
| Pushbutton Material | Plastic |
| Amperage | 3 @ 125 VAC |
| Voltage | 125 VAC |
| Contact Configuration | NO |
| Contact Form | SPST |
| Terminal Type | Solder Eyelet |
| Bushing Length (Decimal Inch) | 0.3150 |
