Associated Spring Raymond - 6.93mm OD, 0.64mm Wire, 17mm Free Length, Compression Spring - 6.7 Lb Spring Rating, 12.45 N Max Work Load, Music Wire
Item #: 06152573
Brand: Associated Spring Raymond
Model #: D11510
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.93 |
| Outside Diameter (Decimal Inch) | 0.2730 |
| Free Length (mm) | 16.99 |
| Free Length (Decimal Inch) | 0.6690 |
| Spring Rate Pounds per Inch (Pounds) | 6.7000 |
| Maximum Work Load (N) | 12.44999981 |
| Solid Height (mm) | 5.36 |
| Solid Height (Decimal Inch) | 0.2110 |
| Material | Music Wire |
| Wire Size (mm) | 0.64 |
| Wire Size (Decimal Inch) | 0.0250 |
