Gates - Belts Belt Style: Synchronous Belt Section: Round
Item #: 96339064
Brand: Gates
Model #: 90122076
Product Specifications
Belts; Belt Style: Synchronous ; Belt Section: Round ; Outside Length: 28.992 (Decimal Inch); Outside Length: 736.40 (mm); Belt Width: 0.591 (Decimal Inch); Belt Width: 15.00 (mm)
| Belt Style | Synchronous |
| Belt Section | Round |
| Outside Length (Decimal Inch) | 28.992 |
| Outside Length (mm) | 736.40 |
| Belt Width (Decimal Inch) | 0.591 |
| Belt Width (mm) | 15.00 |
| Belt Number | 740-5M-15 |
| Belt Internal Length (Decimal Inch) | 29.13 |
| Belt Internal Length (mm) | 740.00 |
| Number of Ribs | 0.000 |
| Number of Teeth | 148 |
| Belt Pitch | 5 mm |
| Material | Neoprene |
| Belt Height | 0.22 |
| Color | Black |
| Style | Synchronous |
| Maximum Temperature (F) | 180 |
