US Motors - 1/3 hp, ODP Enclosure, Manual Thermal Protection, 1,625 RPM, 115 Volt, 60/50 Hz, Single Phase Permanent Split Capacitor (PSC) Motor - Size 56 Frame, Cradle Mount, 1 Speed, Ball Bearings, 3.9/4.2 Full Load Amps, B Class Insulation, Reversible
Item #: 04091765
Brand: US Motors
Model #: D13ARM2N9
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Motor Type | Single Phase Permanent Split Capacitor (PSC) |
| Type of Enclosure | ODP |
| Horsepower | 1/3 |
| Thermal Protection Rating | Manual |
| Name Plate RPMs | 1625 |
| Voltage | 115 |
| Frequency Hz | 60/50 |
| Frame Size | 56 |
| Mount Type | Cradle |
| Number of Speeds | 1 |
| Bearing Type | Ball |
| Full Load Amperage | 3.9/4.2 |
| Insulation Class | B |
| Overall Length (Decimal Inch) | 10.8100 |
| Shaft Diameter x Length (Inch) | 5/8 x 1-7/8 |
| Full Load Efficiency Rating | 63.00 |
| Service Factor Rating | 1.00 |
| Motor Rotation | Reversible |
| PSC Code | 6105 |
