Made in USA - 32 Pitch, 7/8" Pitch Diam, 15/16" OD, 28 Tooth Spur Gear - 3/16" Face Width, 3/16" Bore Diam, 1/2" Hub Diam, 20° Pressure Angle, Acetal
Item #: 03125390
Brand: Made in USA
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Spur Gear |
| Number of Teeth | 28 |
| Hub Diameter (Decimal Inch) | 0.5000 |
| Hub Diameter (Inch) | 1/2 |
| Pitch Diameter (Decimal Inch) | 0.8750 |
| Bore Diameter (Inch) | 3/16 |
| Bore Diameter (Decimal Inch) | 0.1875 |
| Material | Acetal |
| Face Width (Inch) | 3/16 |
| Face Width (Decimal Inch) | 0.1880 |
| Pressure Angle | 20 |
| PSC Code | 3020 |
