Brand: Ingersoll Cutting Tools / Part #: 3007751
Item #: 72969504
Brand: Ingersoll Cutting Tools
Model #: 3007751
Product Specifications
| Minimum Cutting Diameter (mm) | 305.56 |
| Minimum Cutting Diameter (Decimal Inch) | 12.0300 |
| Maximum Cutting Diameter (Inch) | 12-1/4 |
| Maximum Cutting Diameter (Decimal Inch) | 12.2500 |
| Maximum Depth of Cut (Decimal Inch) | 0.2300 |
| Arbor Hole Diameter (Decimal Inch) | 2.5000 |
| Arbor Hole Diameter (Inch) | 2-1/2 |
| Lead Angle | 20.000 |
| Compatible Insert Size Code | 0804 |
| Cutter Style | 4W2A |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Rake | Negative |
| Series | 4W2A |
| Keyway Width (Decimal Inch) | 1.0000 |
| Keyway Width (Inch) | 1 |
| Overall Height (Mm - 5 Decimals) | 60.20000 |
| Overall Height (Decimal Inch) | 2.3700 |
| Pitch Type | Coarse |
| Tool Application | Facing; Countersinking |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Complete Insert Compatibility | PNCU0805; PNCQ0804 |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | 4W2A-12R01 |
| Number Of Cutter Inserts | 14 |
| Coolant Through | No |
| Number Of Flutes | 14 |
