De-Sta-Co - 99 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp - M5 Port, 250 Max psi, 99° Bar Opening, 17.27mm Height Under Bar
Item #: 02500700
Brand: De-Sta-Co
Model #: 812-U-LC
Exact Tooling IR#: 04
Features and Benefits
Horizontal mounts indicate that the cylinder is mounted parallel to the clamping bar's closed position.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Horizontal |
| Holding Capacity - Inner (N) | 440 |
| Holding Capacity - Inner (Lb.) | 99 |
| Height Under Bar (mm) | 17.27 |
| Height Under Bar (Decimal Inch) | 0.68 |
| Port Size | M5 |
| Bar Opening (Degrees) | 99 |
| Length Distance Between Mount Holes (mm) | 16.00 |
| Length Distance Between Mount Holes (Decimal Inch) | 0.6300 |
| Width Distance Between Mount Holes (mm) | 23.88 |
| Width Distance Between Mount Holes (Decimal Inch) | 0.9400 |
| Clamping Force - Inner (N) | 613 |
| Clamping Force - Inner (Lb.) | 138 |
| Bar Extension (Decimal Inch) | 1.0200 |
| Bar Extension (mm) | 25.91 |
| Overall Open Length (mm) | 116.08 |
| Overall Open Length (Decimal Inch) | 4.57 |
| Overall Closed Length (mm) | 141.99 |
| Overall Closed Length (Decimal Inch) | 5.59 |
| Overall Open Height (Decimal Inch) | 2.76 |
| Overall Open Height (mm) | 70.10 |
| Overall Closed Height (mm) | 39.62 |
| Overall Closed Height (Decimal Inch) | 1.56 |
| Outer Clamping Force (N) | 413 |
| Outer Clamping Force (Lb.) | 93 |
| Maximum Air Pressure (psig) | 250.00 |
| Maximum Air Pressure (bar) | 17.00 |
| Mounting Hole Size (mm) | 4.32 |
| Mounting Hole Size (Decimal Inch) | 0.1700 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 2.9:1; 4.3:1 |
| Cylinder Bore Size (mm) | 19.05 |
| Cylinder Bore Size (Decimal Inch) | 0.7500 |
| Spindle Thread Size | M5 |
| Maximum Operating Temperature (C) | 74.00 |
| Maximum Operating Temperature (F) | 165.20 |
| Minimum Operating Temperature (F) | -9.40 |
| Minimum Operating Temperature (C) | -23.00 |
| Includes | Spindle Assembly |
