Seco - LCGN1603 FG Grade CP500, Internal/External Threading Insert - 1.75 to 30mm & 14 to 8 TPI Ext Pitch, Neutral Insert, TiAlN/TiN Finish, Carbide
Item #: 02326353
Brand: Seco
Model #: 34046
Exact Tooling IR#: 04
Features and Benefits
TiAlN/TiN is a multilayer coating that combines the high hardness of TiN and the heat resistance of TiAlN. It is commonly used on softer materials in general purpose applications.
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | LCGN |
| Insert Size | 1603 |
| Thread Type | Internal/External |
| Insert Hand | Neutral |
| Material Grade | Micrograin |
| Manufacturer's Grade | CP500 |
| External Pitch/TPI | 1.75-3.00 mm; 14-8 TPI |
| Coating | TiAlN/TiN |
| Material | Carbide |
| Coating Process | PVD |
| Corner Radius (Decimal Inch) | 0.0070 |
| Thickness (Decimal Inch) | 0.1770 |
| Series | MDT |
| Included Angle of Threading Tip | 55 |
| Chipbreaker | FG |
