Eaton Cutler-Hammer - SPST Heavy Duty On-Off-On Toggle Switch - Screw Terminal, Bat Handle Actuator, 1/2 hp at 50 VAC hp, 125/250 VAC & 28 VDC
Item #: 01575562
Brand: Eaton Cutler-Hammer
Model #: E10T115GS
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Switch Type | Heavy Duty |
| Switch Sequence | On-Off-On |
| Contact Form | SPST |
| Actuator Type | Bat Handle |
| Horsepower (HP) | 1/2 @ 50 VAC |
| Terminal Type | Screw |
| Maximum Amperage at 125 Volts | 15 |
| Maximum Amperage at 250 Volts | 10 |
| Mounting Type | Panel Mount |
| Body Material | Nickel Plated |
| Bushing Length (mm) | 11.90 |
| Bushing Length (Decimal Inch) | 0.4700 |
| Voltage | 125/250 VAC; 28 VDC |
| Standards Met | CSA File LR40068 Certified; UL Recognized |
