Southwire - RG6, 75 Ohm, 18 AWG, Coaxial Cable - 1,000 Ft. Long, 0.3 Inch Diameter, Steel Conductor, PVC Jacket
Item #: 01383736
Brand: Southwire
Model #: 920410608
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cable Type | Coaxial |
| Coaxial Type | RG6 |
| Impedance (Ohms) | 75 |
| Shield Type | Braid; Foil |
| Wire Size (AWG) | 18 |
| Outside Diameter (Decimal Inch) | 0.3000 |
| Jacket Color | Black |
| Overall Length (Feet) | 1000 |
| Resistance Features | Sun Resistant |
| Jacket Material | PVC |
| Conductor Material | Steel |
| Attenuation (dB/100 Feet) | 0.85 |
| Capacitance (pF/ft) | 17 |
| Shield Coverage (%) | 40/60 |
| Maximum Operating Temperature (F) | 167 |
| Standards Met | 820; ETL Dual Listed; NEC Article 725/800; RoHS Compliant 2011/65/EU; UL 1581 |
| PSC Code | 6145 |
