Vlier - 0.0643" Body Length x 5/16" Body Diam, 4 Lb Init to 10 Lb Final End Force, Stainless Steel Press Fit Ball Plunger - 1/4" Ball Diam, 0.09" Max Ball Reach, 0.045" Flange Thickness
Item #: 01360999
Brand: Vlier
Model #: DSPFB56
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (Decimal Inch) | 0.3120 |
| Body Length (Decimal Inch) | 0.0643 |
| Body Material | Stainless Steel |
| Ball Material | Nylon |
| Flange | Yes |
| Maximum Ball Reach (Decimal Inch) | 0.0900 |
| Initial End Force (Lb.) | 4.00 |
| Final End Force (Lb.) | 10.00 |
| Length Under Flange (Decimal Inch) | 0.6430 |
| Flange Diameter (Decimal Inch) | 0.3750 |
| Flange Thickness (Decimal Inch) | 0.0450 |
| Ball Diameter (Decimal Inch) | 0.2500 |
| Finish/Coating | Passivate |
| Locking Element | No |
