Vlier - 0.0471" Body Length x 1/4" Body Diam, 1.5 Lb Init to 3.5 Lb Final End Force, Steel Press Fit Ball Plunger - 3/16" Ball Diam, 0.07" Max Ball Reach, 0.045" Flange Thickness
Item #: 01360775
Brand: Vlier
Model #: DPFB53
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (Decimal Inch) | 0.2500 |
| Body Length (Decimal Inch) | 0.0471 |
| Body Material | Steel |
| Ball Material | Nylon |
| Flange | Yes |
| Maximum Ball Reach (Decimal Inch) | 0.0700 |
| Initial End Force (Lb.) | 1.50 |
| Final End Force (Lb.) | 3.50 |
| Length Under Flange (Decimal Inch) | 0.4710 |
| Flange Diameter (Decimal Inch) | 0.3120 |
| Flange Thickness (Decimal Inch) | 0.0450 |
| Ball Diameter (Decimal Inch) | 0.1870 |
| Finish/Coating | Black Oxide |
| Locking Element | No |
