Electro Hardware - M4x0.70, 40.53mm OAL, 6mm Across Flats, Brass Hex Male/Female Circuit Board Standoffs - 11.1mm Thread Depth, 31mm Body Length, Zinc-Plated Finish
Item #: 00320747
Brand: Electro Hardware
Model #: MMF1853M03F21M4
Exact Tooling IR#: 04
Features and Benefits
Circuit board standoffs with male/female threads have one externally threaded end and one internally threaded end. The female end accepts male fasteners or other standoffs.
Brass is an alloy of copper and zinc that is durable, nonmagnetic and conductive.
| Product Specifications | |
|---|---|
| Thread Type | Male/Female |
| Material | Brass |
| System of Measurement | Metric |
| Body Shape | Hex |
| Overall Length (mm) | 40.53 |
| Thread Size | M4x0.70 |
| Width Across Flats (mm) | 6.00 |
| Finish/Coating | Zinc-Plated |
| Body Length (mm) | 31.00 |
| Thread Length (mm) | 9.53 |
| Thread Depth (mm) | 11.10 |
| Length Tolerance (mm) | -0.150 to 0.150 |
| Fastener Standard | ASTM B633 Type 1; QQ-B-626 Comp 22 |
