Eaton Cutler-Hammer - 70 Amp, 120/240 VAC, 2 Pole, Plug In Type CH Circuit Breaker - Thermal Magnetic Trip, 10 kA Breaking Capacity, 14-10 AWG
Item #: 00104893
Brand: Eaton Cutler-Hammer
Model #: CH270
Exact Tooling IR#: 04
Features and Benefits
Type CH circuit breakers are designed to trip cuircuits in severe conditions. They are constructed with thermal-magnetic trip curve that avoids nuisance tripping on mild overloads.
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Type CH Circuit Breaker |
| Amperage | 70 |
| Number of Poles | 2 |
| Breaking Capacity | 10 kA |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Screw |
| Mounting Type | Plug-in |
| Voltage | 120/240 VAC |
| Wire Size (AWG) | 14-10 |
| Standards Met | Federal Specification W-C-375; UL 489 |
| Reset Actuator Type | Handle |
