Heli-Coil - Single Insert, 3/8-24 UNF, 1D, Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 3/8 Inch Overall Length, 0.448 to 0.468 Inch Outside Diameter, with Tang, Bright Finish, 304 Material Grade
Item #: 00063305
Brand: Heli-Coil
Model #: A3591-6CN375
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 3/8-24 |
| Overall Insert Length (Decimal Inch) | 0.3750 |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Number of Inserts | 1 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.4480 |
| Maximum Outside Diameter (Decimal Inch) | 0.4680 |
| Finish/Coating | Bright |
| Number of Free Coils | 6-7/8 |
| Maximum Locking Torque (In/Lb) | 80 |
| Mininum Break Away Torque (oz-in) | 9.50 |
| Thread Standard | UNF |
| Material Grade | 304 |
